Remarks:
IP66: using the membrane entry
IP67: using the threaded entry together with ESKV cable gland
Equipment:
- 6x M20 threaded membrane entries and 1 middle M20 threaded membrane entry with knockout to M25
- 2 membrane cable entries through rear
- 4 captive cover screws
- including mounting clip
- with terminal block 5-poles, 4mm²
Fixing:
With mounting clip or 4 internal openings outside of the sealing area
| Material |
Polypropylene |
| Material sealing gasket |
TPE |
| Temp. range min |
-30 °C |
| Temp. range max |
100 °C |
| Temperatures during install. |
-5 °C - 60 °C |
| Protection class |
IP66 / IP67 |
| Glow wire test |
750 °C |
| Voltage |
690 V |
| Rated current / A (Terminal) |
32 A |
| Rated cross section |
4 mm² |
| Terminals/poles |
5-pole, 4,0 mm² |
| Fixing |
4 internal openings |
| Ø cable diameter min |
3 mm |
| Ø cable diameter max |
12 mm |
| External dimensions LxWxH |
95 x 95 x 60mm |
| Type of cable gland |
M 20 x 1,5, M 25 x 1,5 |
| Using for cable gland |
 |
| Product Color |
RAL 9005 |
| WISKA-Order no. |
10105602 |
| Type |
COMBI 407/5 BK |
| Packing unit |
5 |
| ETIM-Classification |
EC002600 |
